Wise Blind VFREE 3 Outputs 24V White
Product code WISE BLIND VFREE
£64.38
ex. VAT
Wireless control unit for 24V rolling shutter motors for integration into the rolling shutter casing. Open-stop-close function. Input for 1 dynamic push button.
Wireless control unit for 24V motors for Venetian blinds with openstop- close function. It allows regulating the inclination of the blinds. Input for command through an external push button.
Two operating ways are possible:
Short impulses (from 50 to 300ms), the partial inclination of the position of the Venetian blinds both in the opening and in the closing directions.
Impulses longer that 300ms, the complete automatic movement of the Venetian blinds in the opening and in the closing directions.
- Wireless platform — no rewiring between switches and receivers
- Programmed by button-press — no software, hub or app required to set up
- Free installer training and UK technical support from the Wandsworth team
Free training available for installers — book a slot.
Specifications
| Dimensions | |
|---|---|
| Height | 2mm |
| Length | 12.5mm |
| Width | 3.5mm |
| Electrical | |
| Amperage | 5A |
| Voltage | 24V |
| General | |
| Colour | White |
| Construction | Plastic |
| IP Rating | IP44 |
Downloads
Spec sheets
Catalogues
Common questions
Do I need Wi-Fi for this to work?
No. The Wise platform runs on radio frequency (RF), independent of your home Wi-Fi or broadband. The system continues to function during internet outages.
Is special programming software required?
No software, hub or laptop is needed for standard setup. Pairing is done by pressing buttons on the receiver and transmitter in sequence — any qualified installer or competent homeowner can do it.
Can I add this to an existing Wise installation?
Yes. Any new Wise receiver or transmitter pairs directly with existing kit. There's no version lock — Wise Box receivers, Scene controllers and Fusion dimmers all live on the same RF platform regardless of generation.
Does it need a qualified electrician to install?
Wireless transmitters (keypads, remotes, PIRs) can be installed by a competent person without mains work. Receivers and dimmers wire into the mains supply and must be installed by a qualified electrician. Free training is available — see our training page.
Where can I buy it?
Wise Controls equipment is sold through authorised electrical wholesalers nationwide — see our stockists page for the full list, or contact us for the closest distributor to your project.
