Wise Prism Master 12/24V 5 x 100W

Product code WISERGB/W/W
£154.50 ex. VAT
The Wise Prism Master is a RGBWW or WWWWW dimmer with built-in radio receiver for the control of RGB (red, green, blue) and tunable white controller for 12/24 Vdc LED. It allows adjusting the temperature of the colour, mixing the outputs from cool white to warm white. Ideal for outdoor installations using box IP54. Maximum wattage is 100W for each channel, which is 5 x 100W.

  • If controlled with 7-channel wireless transmitter, you can choose from 8 pre-set colours (changeable at any time) or activate the automatic colour cycle
  • The RGB and white outputs are controlled independently by transmitter or manually operated pushbuttons
  • It is possible to adjust the intensity of the pre-set colours and to save the new value (Light memory)
  • Function of gradual light switching on and off (Fade)
  • Possibility to memorize up to 42 transmitters

WISERGBWW Programming

  • Wireless platform — no rewiring between switches and receivers
  • Programmed by button-press — no software, hub or app required to set up
  • Free installer training and UK technical support from the Wandsworth team
Find a stockist Enquire about this product
Free training available for installers — book a slot.

Specifications

Radio Frequency 868.3 MHz
Range for Metal Switch 50m Max Line Of Sight
Range for Plastic Switch 100m Max Line Of Sight
Dimensions
Height 51mm
Length 230mm
Width 70mm
Electrical
Input Voltage 12-24V
Maximum Wattage 500W (5 x 100W)
Minimum Wattage 1W
Voltage 24V
General
Construction Plastic
IP Rating IP54

Downloads

Manuals & instructions

Common questions

Do I need Wi-Fi for this to work?
No. The Wise platform runs on radio frequency (RF), independent of your home Wi-Fi or broadband. The system continues to function during internet outages.
Is special programming software required?
No software, hub or laptop is needed for standard setup. Pairing is done by pressing buttons on the receiver and transmitter in sequence — any qualified installer or competent homeowner can do it.
Can I add this to an existing Wise installation?
Yes. Any new Wise receiver or transmitter pairs directly with existing kit. There's no version lock — Wise Box receivers, Scene controllers and Fusion dimmers all live on the same RF platform regardless of generation.
Does it need a qualified electrician to install?
Wireless transmitters (keypads, remotes, PIRs) can be installed by a competent person without mains work. Receivers and dimmers wire into the mains supply and must be installed by a qualified electrician. Free training is available — see our training page.
Where can I buy it?
Wise Controls equipment is sold through authorised electrical wholesalers nationwide — see our stockists page for the full list, or contact us for the closest distributor to your project.
